THERMALTAKE Commander G33 ARGB Tempered Glass Mid Tower Chassis
SPECIFICATION
|
Attribute |
Value |
|
SERIES |
Commander |
|
MODEL |
G33 TG ARGB |
|
CASE TYPE |
Middle Tower |
|
DIMENSION (H X W X D) |
442 x 225 x 472 mm (17.4 x 8.85 x 18.58 inch) |
|
NET WEIGHT |
7.72 kg / 17.02 lb |
|
PANEL |
4mm Tempered Glass x1 |
|
COLOR |
Exterior & Interior: Black |
|
MATERIAL |
SPCC |
|
COOLING SYSTEM |
Front (intake): 200 x 200 x 30mm Addressable RGB fan (600rpm, 24dBA) x 1, Rear (exhaust): 120 x 120 x 25 mm fan (1000rpm, 16 dBA) |
|
DRIVE BAYS |
Accessible: 2 x 3.5“ or 2.5” (HDD Rack); 2 x 2.5” (HDD Bracket) |
|
EXPANSION SLOTS |
7 + 2 |
|
MOTHERBOARDS |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
|
I/O PORT |
USB 3.0 x 1, USB 2.0 x 2, HD Audio x 1, RGB Switch x 1 |
|
PSU |
Standard PS2 PSU (optional) |
|
FAN SUPPORT |
Front: 120mm x 3, 140mm x 2, 200mm x 2, Top: 120mm x 2, 140mm x 2, Rear: 120mm x 1, 140mm x 1 |
|
RADIATOR SUPPORT |
Front: 280mm x 1, 360mm x 1, Top: 240mm x 1, Rear: 120mm x 1 |
|
CLEARANCE |
CPU cooler height limitation: 165mm, PSU length limitation: 160mm (With HDD Rack) / 200mm (Without HDD Rack), VGA length limitation: 300mm, VGA width limitation (Vertically): 45mm, RAM height limitation: 40mm (With radiator series) |
