Radiator Size

240 mm

Radiator Dimensions (WxDxH)

277 x 119.2 x 27mm / 10.91 x 4.69 x 1.06 inches

Radiator Material

Aluminum

Water Cooling Tube Material

EPDM

Number of Fans

2

Fan Dimensions (WxDxH)

120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches

Fan Air Flow

70.7 CFM

Fan Bearing

Loop Dynamic Bearing (LDB)

Fan Life Expectancy

30,000 hrs @ 40℃

Fan Rated Current

0.2A (Max: 0.3A)

Fan Power Consumption

2.4W (Max: 3.6W)

PWM Mode

Yes

Cable Length (PWM Cable)

550 / 500 mm; 21.65 / 19.69 inches

Fan Connector

- 5V ARGB 3-PIN Header
- PWM 4-PIN Header

Block Lighting

ARGB GEN2

Fan Lighting

ARGB GEN2

Pump Life Expectancy

50,000 hours in typical use

Pump Noise Level

20 dBA (avg.)

Pump Rated Current

0.32A (Max: 0.5A)

Pump Power Consumption

3.84W (Max: 6W)

Pump Speed

3400 RPM ± 10%

Pump Connector

- PWM 4-PIN Header
- 5V ARGB 3-PIN Header (Female)
- 5V ARGB 3-PIN Header (Male)

Cold Plate Material

Copper

Block Dimensions (WxDxH)

69.1 x 74 x 62.45 mm

Intel Socket Support

LGA 1150 / 1151 / 1155 / 1156 / 1200 / 1700 / 1851

AMD Socket Support

AM5 / AM4

Accessories

Thermal paste x 1
