General

Phase

Single Phase

Form Factor

Tower

UPS Topology

Online Double Conversion

Energy Saving Technology

ECO Mode Efficiency > 95%

Active PFC Compatibility

Yes

Input

Generator Compatibility

Yes

Nominal Input Voltage (Vac)

220 ± 25%

Input Voltage Range (Vac)

110 ~ 300

Adjustable Voltage Range (Vac)

110300V @ 0–50% Load<br>120300V @ 0–60% Load
140300V @ 0–80% Load<br>160300V @ 0–100% Load

Input Frequency (Hz)

50 ± 10 / 60 ± 10

Input Frequency Detection

Auto-sensing

Rated Input Current (A)

4.5

Input Power Factor

0.98

Input Connector Type

IEC C14

Detachable Power Cord Plug Type

AS x 1

Power Cord Length (ft)

5

Power Cord Length (m)

1.5

Output

Capacity (VA)

1000

Capacity (Watts)

800

On Battery Waveform

Pure Sine Wave

On Battery Voltage(s) (Vac)

208 / 220 / 230 / 240 ± 1% (Configurable)

On Battery Frequency (Hz)

50 ± 0.5% / 60 ± 0.5%

Output Frequency Setting

Configurable

Power Factor

0.8

ECO Mode Voltage Tolerance

± 15%

Overload Protection

Internal Current Limiting, Circuit Breaker, Fuse

Overload Protection (Line Mode)

110–120% for 1 min, >120% immediately

Overload Protection (Battery Mode)

110–120% for 10 sec, >120% immediately

Overload Protection (Bypass Mode)

>130% immediately

Crest Factor

3:1

Harmonic Distortion (Linear Load)

THD < 3%

Harmonic Distortion (Non-linear Load)

THD < 5%

Internal Bypass

Automatic Bypass, Manual Bypass

Outlet(s) – Total

3

Outlet Type

IEC C13 x1, AS x2

Outlet(s) – Battery & Surge Protected

3

Typical Transfer Time (ms)

0

Battery

Runtime at Half Load (min)

6.9

Runtime at Full Load (min)

2.7

Typical Recharge Time (Hours)

4

Maximum Charging Current (A)

1

Start On Battery

Yes

Smart Battery Management (SBM)

Yes

User-replaceable

No

Battery Type

Sealed Lead-acid

Single Battery Capacity (AH)

12 V / 7 AH

Surge Protection & Filtering

Surge Suppression (Joules)

220

EMI/RFI Filtration

Yes

Management & Communications

LCD Panel

Yes

LCD Types

Color LCD

LCD Information Display

Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Info, Event & Log

LCD Setting & Control

Mode Setting, Alarm Setting, Input & Output, Battery Setting

HID Compliant USB Port(s)

1

Audible Alarms

Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery

Management Cable (pcs)

USB Cable x1

Power Management Software

PowerPanel Business (Recommended)

SNMP/HTTP Remote Monitoring

Yes – with optional RMCARD205

Physical

Enclosure Construction

Metal

Color

Black

Dimensions (WxHxD) (in)

5.5 x 7.5 x 12.9

Dimensions (WxHxD) (mm)

140 x 191 x 327

Weight (lbs)

29.1

Weight (kg)

13.2

Environmental

Operating Temperature (°F)

32 ~ 104

Operating Temperature (°C)

0 ~ 40

Operating Relative Humidity

0 ~ 95% (non-condensing)

Operating Elevation

0 – 4,921 ft (0 – 1,500 m)

Storage Temperature (°F)

-4 ~ 122

Storage Temperature (°C)

-20 ~ 50

Storage Relative Humidity

10 ~ 90% (non-condensing)

Storage Elevation

0 – 4,921 ft (0 – 1,500 m)

Online Thermal Dissipation (BTU/hr)

270

Variable Speed Fans

20 steps automatically

Certifications

Certifications

CE

RoHS

Yes
