Battery Capacity

320Wh (20Ah)

Battery Type

LiFePO4

Weight

About 4.3 kg / 9.48 lbs

Dimensions (L × W × H)

250 × 178 × 167.5 mm (9.8 × 7 × 6.6 in)

Charging Temperature

0°C to 40°C (32°F to 104°F)

Discharging Temperature

-20°C to 40°C (-4°F to 104°F)

Storage Temperature

-20°C to 40°C (-4°F to 104°F)

Operating Humidity

10% to 90%

Input

AC Charging

380W max; 80% in 45 mins @ 25°C / 77°F

AC Input (with Bypass)

980W max

DC Input

200W max; 12V–28V, 10A max

AC + DC Input

380W max

Output

AC Output

600W total; 120V, 5A, 50Hz/60Hz

Switchover Time

≤10 ms

UPS (Uninterruptible Power Supply)

Supported

Cigarette Lighter Port

1 × 12V/10A

DC5521 Ports

2 × 12V/5A (per port), 8A total

USB-A Ports

2 × 5V/3A (per port), 15W max

USB-C (100W)

1 × 100W max; 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A

USB-C (140W)

1 × 140W max; 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A, 28V/5A

AC + DC Output

600W max

Protection

IP Rating

IP20
